Universal Analog Input

Universal Analog Input

Transform your analog keyboard input into gamepad controls for any game.

Installation | Features | Usage | Contributing

Rust Inside Windows WinUI 3

[!TIP] Don’t have an analog keyboard? See Keyboard Sim to simulate analog input with a regular keyboard and mouse.

Overview

Universal Analog Input bridges the gap between analog keyboards and games that don’t natively support them. It captures precise analog input from your keyboard and translates it into virtual gamepad controls, giving you smooth, proportional movement in any game that supports controllers.

Why Universal Analog Input?

Most games treat keyboard input as binary (pressed or not pressed), resulting in all-or-nothing movement. In racing games, for example, pressing a key means full acceleration or full steering, there’s no in-between. With analog keyboards, you can press keys partially, but most games don’t recognize this capability.

Universal Analog Input solves this by converting analog keyboard input into virtual gamepad controls — giving you smooth, proportional movement in any game that supports controllers. See Features for the full list of capabilities.


In game experience :

Dark-Transparent-Explanation Light-Explanation


Video Demo

https://github.com/user-attachments/assets/36757e45-80f2-4242-9abb-7bc620788564


Features

Core Capabilities

Feature Description
Analog Input Capture Integration with Wooting Analog SDK to capture precise analog input values
Virtual Gamepad Emulation ViGEm-powered Xbox controller emulation
Flexible Key Mapping Map any analog keyboard key to gamepad sticks, triggers, or buttons
Response Curves Choose from linear or custom interpolated response curves
Dead Zone Configuration Inner and outer dead zones for precise control calibration
Profile Management Save separate configurations for each game you play
Sub-Profile System Multiple mapping sets per game for different situations (driving, walking, etc.)
Hotkey Switching Instantly switch between sub-profiles during gameplay
Real-time Visualization Live input monitoring in the “Tester” tab
Error Monitoring Optional Sentry integration for crash reports and stability metrics

Advanced Features


Installation

Prerequisites

Before installing Universal Analog Input, ensure you have:

  1. Windows 10/11 (version 1903 or later)
  2. Analog Keyboard - Wooting or any keyboard supported via the Universal Analog Plugin

Download

Installer (Recommended)

Download the latest installer: UniversalAnalogInput-Setup-v1.0.1.exe

The installer automatically handles:

Build from Source Alternatively, you can build from source: **Requirements:** - [.NET 9 SDK](https://dotnet.microsoft.com/download/dotnet/9.0) - [Rust toolchain](https://rustup.rs/) - [Visual Studio 2022](https://visualstudio.microsoft.com/) with Windows App SDK (optional, for UI development) **Build Steps:** ```bash # Clone the repository git clone https://github.com/Ritonton/UniversalAnalogInput.git cd universal-analog-input # Build everything (Rust core + C# interface) .\scripts\build.ps1 # Package for local distribution (creates UniversalAnalogInput.exe + published UI folder) .\scripts\package.ps1 -SelfContained # The executable will be in the output directory ```


Usage

Quick Start Guide

  1. Connect Your Analog Keyboard
    • Plug in your keyboard before launching the app
  2. Launch Universal Analog Input
    • Run UniversalAnalogInput.exe
    • The system tray icon will appear
    • The configuration interface opens automatically on first run
    • Verify your keyboard is detected in the app
  3. Create Your First Profile
    • Click “New Profile” to create a game configuration
    • Name it after your game (e.g., “GTA V”)
    • Add sub-profiles if needed (e.g., “Driving”, “On Foot”)
  4. Map Your Keys
    • Select a key from the “Supported Keys” list
    • Choose a gamepad control (stick, trigger, or button)
    • Configure response curve and dead zones in “Curves” tab
    • Click “Add Mapping”
  5. Test Your Configuration
    • Switch to the “Tester” tab
    • Press your mapped keys and watch the gamepad visualization
    • Adjust curves and dead zones as needed
  6. Start Playing
    • Click “Start Mapping” to activate your profile
    • Launch your game (it must support Xbox-style controllers)
    • The mapping runs in the background via the system tray

[!IMPORTANT] Avoid key conflicts in your game’s settings. When UAI is active, your analog keys are translated into gamepad inputs. If your game also has those same keyboard keys bound to an action, the game will receive both a gamepad signal and a keyboard signal on the same action simultaneously, causing erratic behavior. To prevent this, go to your game’s key bindings and unbind any key you have mapped in UAI (set it to “None”), or reassign it to an unused key.

Profile Management

Creating Sub-Profiles

Import/Export Profiles

Hotkeys


Architecture

Universal Analog Input uses a hybrid architecture separating the core engine from the user interface.

Analog Data Flow ### From Key Press to Game Input ```mermaid flowchart LR KB["Analog Keyboard (Hall Effect switches 0.0–1.0 per key)"] subgraph BRIDGE["Non-Wooting keyboards"] direction TB UAP["Universal Analog Plugin by AnalogSense"] end WSDK["Wooting Analog SDK (unified analog API)"] subgraph UAI["Universal Analog Input"] direction TB DZ["Dead Zone Filter (inner & outer)"] RC["Response Curve (linear or custom)"] MAP["Key to Gamepad Mapping"] DZ --> RC --> MAP end VIGEM["ViGEm Bus Driver (virtual Xbox controller)"] GAME["Game (XInput or DirectInput)"] KB -->|"raw analog values"| UAP UAP -->|"normalized values"| WSDK KB -->|"Wooting native direct path"| WSDK WSDK -->|"per-key analog values"| UAI UAI -->|"gamepad axis or button state"| VIGEM VIGEM -->|"virtual controller"| GAME style BRIDGE fill:#555,stroke:#888,stroke-width:1px,stroke-dasharray:4 4,color:#ccc style UAI fill:#e67e22,stroke:#a85819,stroke-width:2px,color:#fff style VIGEM fill:#9b59b6,stroke:#7d3c98,color:#fff style WSDK fill:#27ae60,stroke:#1e8449,color:#fff style GAME fill:#4a90e2,stroke:#2e5c8a,color:#fff ``` The **Universal Analog Plugin** is only needed for non-Wooting keyboards. Wooting keyboards communicate directly with the Wooting Analog SDK. In both cases, UAI receives the same normalized per-key values (0.0 – 1.0), applies dead zones and response curves, and forwards the result to ViGEm as a virtual Xbox controller that the game sees as a real gamepad.
Architecture Details ### Component Overview ```mermaid flowchart TB subgraph UI["WinUI 3 Config UI (C#)"] PM["Profile
Management"] KM["Key Mapping
Editor"] RT["Real-time
Tester"] PM --- KM --- RT end IPC["IPC (Named Pipes)"] subgraph Core["Rust Core Engine (System Tray)"] WA["Wooting
Analog SDK"] --> ME["Mapping
Engine"] ME --> VG["ViGEm
Gamepad
Emulation"] PM2["Profile
Management"] HM["Hotkey
Manager"] RC["Response
Curves"] PM2 --- HM --- RC end UI <-->|JSON Payloads| IPC IPC <-->|JSON Payloads| Core style UI fill:#4a90e2,stroke:#2e5c8a,stroke-width:2px,color:#fff style Core fill:#e67e22,stroke:#a85819,stroke-width:2px,color:#fff style IPC fill:#95a5a6,stroke:#7f8c8d,stroke-width:2px,color:#fff style WA fill:#27ae60,stroke:#1e8449,color:#fff style ME fill:#e74c3c,stroke:#c0392b,color:#fff style VG fill:#9b59b6,stroke:#7d3c98,color:#fff linkStyle 0 stroke:transparent linkStyle 1 stroke:transparent linkStyle 4 stroke:transparent linkStyle 5 stroke:transparent ``` ### Technology Stack **Rust Core Engine (`/native`)** - High-performance input processing - Wooting Analog SDK integration with plugin support - ViGEm gamepad emulation - IPC server for communication with UI - System tray application **C# Configuration Interface (`/ui`)** - WinUI 3 for modern Windows interface - Dependency injection with ServiceLocator pattern - Real-time input visualization - IPC client for communication with core **Key Technologies** - [Wooting Analog SDK](https://github.com/WootingKb/wooting-analog-sdk) - Analog keyboard input with plugin system - [Universal Analog Plugin](https://github.com/AnalogSense/universal-analog-plugin) - Multi-keyboard compatibility - [ViGEm](https://github.com/nefarius/ViGEmBus) - Virtual gamepad emulation - [WinUI 3](https://docs.microsoft.com/windows/apps/winui/) - Modern Windows interface - Rust + C# IPC - Separate processes communicating via Windows named pipes (JSON payloads)


Project Structure ``` universal-analog-input/ ├── native/ # Rust core engine │ ├── src/ │ │ ├── bin/ │ │ │ └── tray.rs # System tray application (entry point) │ │ ├── lib.rs # Core library │ │ ├── conversions.rs # Conversion tables │ │ ├── curves.rs # Response curve evaluation │ │ ├── api/ # IPC API definitions │ │ ├── ipc/ # IPC server implementation │ │ ├── mapping/ # Mapping engine │ │ ├── gamepad/ # ViGEm gamepad emulation │ │ ├── wooting/ # Wooting SDK integration │ │ ├── profile/ # Profile management │ │ └── input/ # Hotkey system │ ├── Cargo.toml │ └── build.rs ├── ui/ # C# WinUI 3 interface │ └── UniversalAnalogInputUI/ │ ├── Views/ # XAML pages │ ├── Services/ # Business logic │ ├── Controls/ # Custom controls │ ├── Models/ # Data models │ ├── Dialogs/ # UI dialogs │ └── Helpers/ # Utility functions ├── shared/ # Shared resources │ └── configs/ # Default profiles └── scripts/ # Build automation ├── build.ps1 # PowerShell build script ├── package.ps1 # Packaging script └── create-release.ps1 # Release creation script ```

Development

Building the Project **Quick Build (Development)** ```powershell # Build everything .\scripts\build.ps1 # Build only Rust core cd native cargo build # Build only C# interface cd ..\ui dotnet build ``` **Package for Distribution** ```powershell # Create self-contained package (includes .NET runtime) .\scripts\package.ps1 -SelfContained # Create release ZIP .\scripts\create-release.ps1 -Version "1.0.0" ``` **Visual Studio Development** 1. Open `ui\UniversalAnalogInputUI.sln` 2. Set configuration to `x64 | Release` 3. Build and run with F5
Development Commands **Rust Development** ```bash cd native cargo check # Fast syntax checking cargo clippy # Linting cargo fmt # Format code cargo run --bin uai-tray # Run tray application ``` **C# Development** ```bash cd ui dotnet build # Build solution dotnet run # Run application dotnet clean # Clean artifacts ```


Contributing

Contributions are welcome! Here’s how you can help:

Ways to Contribute

Development Guidelines

  1. Follow existing code style
    • Rust: Use cargo fmt and cargo clippy
    • C#: Follow Microsoft conventions
  2. Update documentation
    • Update README.md for user-facing changes
  3. Keep it simple
    • Write clean, readable code
    • Avoid unnecessary complexity

Pull Request Process

  1. Fork the repository
  2. Create a feature branch (git checkout -b feature/amazing-feature)
  3. Commit your changes (git commit -m 'Add amazing feature')
  4. Push to the branch (git push origin feature/amazing-feature)
  5. Open a Pull Request


Compatible Hardware

Universal Analog Input works with two categories of devices depending on whether the Universal Analog Plugin by AnalogSense is installed.

Without Universal Analog Plugin — Wooting keyboards only

Keyboard
All Wooting keyboards with analog mode

With Universal Analog Plugin — extended compatibility

The plugin bridges third-party analog keyboards to the Wooting Analog SDK, enabling support for all devices below.

Keyboard Notes
Razer Huntsman V2 Analog [R]
Razer Huntsman Mini Analog [R]
Razer Huntsman V3 Pro [R]
Razer Huntsman V3 Pro Mini [R]
Razer Huntsman V3 Pro Tenkeyless [R]
NuPhy HE-series keyboards (Hall Effect line only)
DrunkDeer (all models)
Keychron Q1 HE [P] [F]
Keychron Q3 HE [P] [F]
Keychron Q5 HE [P] [F]
Keychron K2 HE [P] [F]
Lemokey P1 HE [P] [F]
Madlions MAD60 HE [P]
Madlions MAD68 HE [P]
Madlions MAD68R [P]

Notes:

[!NOTE] For NuPhy, only keyboards in the HE (Hall Effect) line are supported — not all NuPhy keyboards. These are the models equipped with Hall Effect switches and the appropriate motherboard for analog output.


No Analog Keyboard? Use Keyboard Sim

Keyboard Sim lets you simulate analog input using a regular keyboard and mouse — no analog hardware required. You can try UAI, build profiles, and test mappings right away.

Download keyboard-sim.exe

Hold any key and scroll the mouse wheel to set its analog value (0–100%). You can also enable Mouse mode to drive keys with physical mouse movement, binding each direction (Up / Down / Left / Right) to one or more keys.

Technical details and build instructions ### How it works Keyboard Sim writes directly into the Wooting Analog Test Plugin shared memory. UAI reads from that same memory, so from its perspective the input is identical to a real analog keyboard. ### Usage 1. Launch **Universal Analog Input** first 2. Launch `keyboard-sim.exe` — it connects automatically 3. Build your profile in UAI as normal, using Keyboard Sim to produce the analog values ### Build from source ```bash cd keyboard-sim cargo build --release # Output: keyboard-sim/target/release/keyboard-sim.exe ```


System Requirements

Minimum Requirements


License

This project is licensed under the MIT License - see the LICENSE file for details.

For information about third-party dependencies and their licenses, see THIRD_PARTY_LICENSES.md.


Acknowledgments


Known Issues


Important Notes


Privacy & Telemetry

Universal Analog Input includes optional error monitoring and crash reporting via Sentry.

Detailed Privacy Information ### Built from Source (Open-Source) If you **build from source**: - Sentry is **disabled by default** - you must set a DSN in the `.env` file to enable it - Set `UI_SENTRY_DSN` and `NATIVE_SENTRY_DSN` environment variables to enable monitoring - Leave them empty or unset to disable completely ### Official Releases (Distributed Binary) If you **download the official release installer**: - Sentry is **enabled by default** to help improve stability and fix bugs faster - **No personal information (PII) is collected** (`send_default_pii: false`) - Crash reports are sent to Sentry servers only when crashes occur - You can **disable Sentry at any time** by editing or removing the `.env` file (see below) ### How to Disable Sentry in Official Release Edit `%LOCALAPPDATA%\UniversalAnalogInput\.env`: ```bash # Comment out or remove these lines to disable Sentry: #UI_SENTRY_DSN=... #NATIVE_SENTRY_DSN=... ``` Or simply delete the `.env` file entirely, the application will run without Sentry monitoring. For full details, see [PRIVACY_POLICY.md](/UniversalAnalogInput/PRIVACY_POLICY.html) and [TERMS_OF_SERVICE.md](/UniversalAnalogInput/TERMS_OF_SERVICE.html).


Changelog

Current Version: 1.0.1 (January 14, 2026)

Latest Release Highlights

See CHANGELOG.md for complete version history and upgrade guide.
